Giant Reign E+ 3 E-Bike – 2023

GIANT REIGN E+ 3 E-BIKE – 2023

Every trail, every steep climb, every thrilling descent. Tested and developed by giant’s e-bike enduro pros, this updated trail ripper gives you the power to enjoy the best parts of the ride again and again.

Trail technology
Proven Maestro rear suspension (160mm) and a powerful but compact SyncDrive Pro motor technology boost your capabilities on steep climbs and rugged descents.

Total control
RideControl Ergo 3 offers integrated, user-friendly button controls that are easy to use. The Giant E-bike App gives you tuning options and E-bike specific fitness tracking.

Long-lasting power
Climb steep mountains and enjoy fun descents all day long with the downtube-integrated EnergyPak.

FEATURES

• ALUXX SL Aluminum Technology
• Hybrid Cycling Technology
• Maestro Suspension Technology
• SyncDrive Pro
• Smart Assist
• Energypak
• RideControl Ergo 3
• RideControl Go

TECH SPECS

• Motor: SyncDrive Pro, 85Nm, powered by Yamaha
• Controller: RideControl Ergo 3, grip integrated
• Display: RideControl GO, frame integrated LED displayANT+ Wireless display compatible
• Battery: EnergyPak Smart 625WhEnergyPak Plus range extender compatible
• Sizes: S, M, L, XL
• Colors: Amber Glow
• Frame: ALUXX SL-grade Aluminum, Advanced Forged Composite Upper Rocker, 160mm Maestro suspension system, ‘Boost’ 148x12mm, UDHTM derrailleur hanger
• Fork: RockShox Domain R 29er, 170mm travel, 15×110 Boost, Maxle Stealth, E-bike Approved
• Shock: Fox Float DPS Performance, EVOL Large Volume sleeve, 2-position lever, 205×62.5mm Trunnion mount, custom tuned
• Handlebar: Giant Contact Trail, 35x800mm
• Grips: Giant Tactal Pro-E, single lock-on
• Stem: Giant Contact SL 35
• Seatpost: Giant Contact Switch, dropper, 30,9mm (S:125, M: 150, L/XL:170)
• Saddle: Giant Romero Trail
• Pedals: Flat pedal
• Shifters: Shimano Deore
• Front Derailleur: MRP 1X HD2 custom co-molded chain guide
• Rear Derailleur: Shimano Deore 12-speed
• Brakes: Shimano Deore BR-M4120, 4-piston, hydraulic disc, 203mm
• Brake Levers: Shimano Deore BL-M4100, I-spec EV
• Cassette: Shimano Deore CS-M6100-12, 10-51T, 12-speed
• Chain: KMC e.12 Turbo, EcoProteq, e-bike optimized
• Crankset: Praxis Wavetm 36T Cold Forged 4130 premium steel Praxis e-Cadet+ custom forged crankarm set (S/M:160, L/XL:165)
• Bottom Bracket: –
• Rims: Giant AM 29″[F] 27.5″[R], Tubeless ready, 30mm inner width
• Hubs: Shimano MT410 Boost, Center-Lock, [F] 110×15 [R] 148x12mm Micro-Spline Drive Body Thru-axle
• Spokes: Sapim E-Lite [r] Race [f]
• Tires: Maxxis Minion DHF 29×2.6″ foldable, Tubeless, EXO+, 3C MaxxTerra[F]Maxxis High Roller II 27.5×2.5″ foldable, Tubeless, DoubleDown, 3C MaxxTerra Compound [R]
• Extras: Tubeless kit (liquid, valves, levers, manual, tool)
• Lighting: Optional:- Giant Recon series e-bike lights available and direct connectable
• Weight: The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
