Norco Bigfoot 1 Bike – 2023

NORCO BIGFOOT 1 BIKE – 2023

Balanced weight distribution for maximum traction and a powerful pedaling position keep the Bigfoot 1 charging forward all year.

The redesigned Bigfoot 1 elevates fat bike performance to downright fun, anywhere, anytime.
The confident, aggressive handling tracks precisely where you want on a descent or technical trail, and the simple one-by drivetrain offers reliable, simple shifts with gloved hands.

FEATURES

• Built from the powder-up with their holistic approach to fit & geometry.
• Big fat tires for max traction and floatation in the deep stuff.
• Frame details add versatility.
• Top tube clearance is critical in fat biking.
• Optimized for the cold, capable year-round.
• Evolved, thoughtful details make it even better.

TECH SPECS

Frameset

• FRAME: Butted X6 Aluminum
• FORK: Full Carbon

Drivetrain

• REAR: SHIFTER Shimano SLX SL-M7100-IR
• REAR: DERAILLEUR Shimano XT RD-M8100
• CRANKSET: Praxis Cadet M30, 32T, 170mm (S), 175mm (M, L, XL)
• BOTTOM BRACKET: Praxis M30, BSA Threaded
• CASSETTE: Shimano SLX, 10/51, 12 Speed
• CHAIN: Shimano Deore

Brakes

• FRONT BRAKE: SRAM Level Hydraulic
• FRONT BRAKE ROTOR: Avid G2, 180mm
• REAR BRAKE: SRAM Level Hydraulic
• REAR BRAKE ROTOR: Avid G2, 160mm
• BRAKE LEVERS: SRAM Level

Components

• HANDLEBAR: Butted 6061 Alloy, 780mm, 20mm Rise
• STEM: 6061 Alloy, 50mm Length, 35mm Clamp
• SEATPOST: X-Fusion Manic Dropper, 31.6mm, 125mm (S), 150mm (M), 170mm (L, XL)
• HEADSET: Sealed Bearing, Tapered
• HEADSET SPACER: 2x10mm – Black
• SADDLE: Fizik Alpaca Terra, Wingflex
• GRIPS: DMR Deathgrip
• PEDALS: VP Nylon Flat
• SEATPOST CLAMP: Alloy Nutted

Wheels

• FRONT HUB: Sealed Bearing, 15x150mm, 6 bolt
• REAR HUB: Bear Pawls, 12x197mm, Micro Spline, 6 Bolt
• RIMS: Sun Ringlé Mulefut SL, 27.5″, 32H
• FRONT TIRE: Vee Snow Avalanche TLR 4.5″, 120 TPI, Studdable
• REAR TIRE: Vee Snow Avalanche TLR 4.5″, 120 TPI, Studdable
• REAR HUB SKEWER: 197mm x 12mm TA
• FRONT HUB SKEWER: 150mm x 15mm TA
• SPOKES/NIPPLES: Stainless 14g, Black
