Specialized Fuse Sport Bike – 2023

SPECIALIZED FUSE SPORT BIKE – 2023

Here’s proof you don’t need tons of suspension travel to tackle challenging trails. Equipped with an all-new longer, lower, and rowdier chassis, Specialized added 27.5×2.6 wheels and tires to the Fuse Sport 27.5 to create a bike that lets you hit rocks and roots at speed with absolute control…

TECH SPECS

Frameset

• Frame: Specialized A1 Premium Aluminum, 148mm thru-axle, tapered head tube, internal cable routing
• Seat Binder: Alloy, 38.6mm

Suspension

• Fork: RockShox Judy Silver TK, air spring, 42mm offset, 130mm of travel

Cockpit

• Stem: Stout 3D-forged alloy, 31.8mm, 6-degree rise
• Handlebars: Stout Riser, double-butted alloy, 9-degree backsweep, 5-degree upsweep, 15mm rise, 750mm / 780mm width, 31.8mm
• Tape: Specialized Trail Grips
• Saddle: Body Geometry Bridge Saddle, steel rails
• SeatPost: TranzX Dropper, 30.9mm, XS-S: 100mm, M-XL: 120mm

Brakes

• Front Brake: SRAM Level, hydraulic disc, 180/160mm
• Rear Brake: SRAM Level, hydraulic disc, 160mm

Drivetrain

• Rear Derailleur: SRAM SX Eagle, 12-speed
• Shift Levers: SRAM SX Eagle, trigger, 12-speed
• Cassette: SRAM PG-1210 Eagle, 11-50t
• Chain: SRAM, SX Eagle, 12-speed
• Crankset: SRAM, SX Eagle, 12-speed Boost, Powespline, 32T
• Bottom Bracket: SRAM Powerspline

Wheels

• Front Hub: Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h
• Rear Hub: Alloy, sealed cartridge bearings, 12x148mm thru-axle, 28h
• Spokes: Stainless, 14g
• Front Tire: Eliminator, GRID TRAIL casing, GRIPTON T7 compound, 2Bliss Ready, 27.5×2.6″
• Rear Tire: Eliminator, GRID TRAIL casing, GRIPTON T7 compound, 2Bliss Ready, 27.5×2.6″
• Inner Tubes: Presta, 40mm valve
