Specialized Stumpjumper Alloy Mountain Bike – 2024

SPECIALIZED STUMPJUMPER ALLOY MOUNTAIN BIKE – 2024

The Stumpjumper Alloy brings all-new suspension kinematics and progressive geometry into a full-alloy package that’s both lightweight and extremely durable. Outfitted with a no-fuss SRAM SX 12-speed groupset, the Stumpjumper Alloy is your all-access pass for trail adventure.

FEATURES

• PROGRESSIVE GEOMETRY — The S-Sizing geometry of the new Stumpjumper hits the progressive sweet spot. It’s long, low and slack, with a short offset fork and a steeper seat tube angle. These numbers combine to make your ride more stable, more carvealicious, more comfortable climbing, more better everywhere. With FlipChip adjustability you’re able to further fine-tune your fit, ensuring that your new Stumpjumper performs flawlessly on whatever terrain you choose.
• THE SWEETEST 130MM OF TRAVEL YOU’LL EVER RIDE — Specialized massaged the kinematics of the Stumpjumper suspension to bring out the very best all-round performance possible in a 130mm package. Countless hours of suspension lab development and field testing created a refined mid-travel ripper that eats big terrain like a gravity fed beast, handles like a dream everywhere, and climbs like it has a motor.
• RIDER-FIRST ENGINEERED — Rider-First Engineered frames use a size-specific approach to ride characteristics that ensures benchmark handling and flawless performance, regardless of frame or rider size. Whether you’re a jump-happy grom riding an S1, or a DH-fiend giant in need of the lengthy S6, you’ll experience the same ride traits – rail-sharp cornering and balanced front and rear stiffness – at the lightest-possible weight, And by light, they mean real light: 2,250 grams (S-Works, S-3 size, with rear shock).
• THE TRAIL BENCHMARK — When Specialized set out to design the all-new Stumpjumper, they pursued some hefty goals. It had to excel on any kind of trail, for every style of rider. To achieve that, Specialized went after serious weight reduction without sacrificing durability, a stiff, responsive chassis that still rides light and lively, geometry that improves everyone’s riding, and the best suspension kinematics they know how to design. Turns out, you can have your cake and eat it too with the new Stumpjumper.

TECH SPECS

FRAMESET

• Frame – Alloy chassis and rear-end, asymmetrical design, 29 Trail Geometry, horst pivot BB adjustment, threaded BB, 12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 130mm of travel
• Seat Binder – Alloy, 38.6mm

SUSPENSION

• Rear Shock – X-Fusion 02 Pro RL, Rx Trail Tune, rebound adjust, lockout S1:190×42.5mm, S2-S6: 190x45mm
• Fork – RockShox 35 Silver, Solo Air, 44mm offset, rebound adjust, TurnKey lockout, 15x110mm Boost Maxle Lite thru-axle, 140mm of travel

COCKPIT

• Stem – Alloy Trail Stem, 35mm bar bore
• Handlebars – Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise, 780mm width
• Tape – Specialized Trail Grips
• Saddle – Body Geometry Bridge Saddle, steel rails
• SeatPost – TranzX dropper, 34.9mm, S1: 100mm, S2: 125mm, S3: 150mm. S4-S5: 170mm, S6- 200mm

BRAKES

• Front Brake – Tektro Gemini Comp, hydraulic disc, resin pad, 200mm
• Rear Brake – Tektro Gemini Comp, hydraulic disc, resin pad, 180mm

DRIVETRAIN

• Rear Derailleur – SRAM SX Eagle, 12-speed
• Shift Levers – SRAM SX Eagle, trigger, 12-speed
• Cassette – SRAM PG-1210 Eagle, 11-50t
• Chain – SRAM SX Eagle, 12-speed
• Crankset – SRAM SX Eagle, S1:165mm, S2-S5: 170mm, S6: 175mm
• Chainrings – 30T
• Bottom Bracket – SRAM Powerspline

WHEELS

• Rims – Double-wall alloy, 27mm internal width, 28h
• Front Hub – Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h
• Rear Hub – Alloy, sealed cartridge bearings, 12x148mm thru-axle, 28h
• Spokes – Stainless, 14g
• Front Tire – Butcher, GRID casing, GRIPTON T7 compound, 29×2.3″
• Rear Tire – Purgatory, GRID casing, GRIPTON T7 compound, 29×2.3″
• Inner Tubes – TUBES,STANDARD 48MM PV LOW LEAD 29×1.75/2.4, MAXXIS BRAND

DIMENSIONS

	S1	S2	S3	S4	S5	S6
Stack (Low BB)	618mm	613mm	623mm	631mm	639mm	649mm
Stack (High BB)	614mm	609mm	618mm	627mm	640mm	644mm
Reach (Low BB)	410mm	430mm	450mm	475mm	500mm	530mm
Reach (High BB)	416mm	435mm	455mm	480mm	505mm	535mm
Headtube Length	100mm	100mm	110mm	120mm	130mm	140mm
Headtube Angle (Low BB)	65°	65°	65°	65°	65°	65°
Headtube Angle (High BB)	65.5°	65.5°	65.5°	65.5°	65.5°	65.5°
BB Height (Low BB)	327mm	332mm	332mm	332mm	332mm	332mm
BB Height (High BB)	334mm	339mm	339mm	339mm	339mm	339mm
BB Drop (Low BB)	47mm	42mm	42mm	42mm	42mm	42mm
BB Drop (High BB)	40mm	35mm	35mm	35mm	35mm	35mm
Trail (Low BB)	126mm	126mm	126mm	126mm	126mm	126mm
Trail (High BB)	122mm	122mm	122mm	122mm	122mm	122mm
Fork Length (full)	550mm	550mm	550mm	550mm	550mm	550mm
Fork Rake/Offset	44mm	44mm	44mm	44mm	44mm	44mm
Front Center	726mm	746mm	770mm	799mm	828mm	863mm
Chainstay Length (Low BB)	444mm	444mm	444mm	444mm	454mm	454mm
Chainstay Length (High BB)	440mm	440mm	440mm	440mm	450mm	450mm
Wheelbase (Low BB)	1168mm	1188mm	1212mm	1241mm	1280mm	1315mm
Wheelbase (High BB)	1164mm	1184mm	1208mm	1237mm	1276mm	1311mm
Top-tube Length (horizontal)	545mm	563mm	586mm	615mm	643mm	676mm
Bike Standover Height	742mm	742mm	750mm	753mm	777mm	784mm
Seat Tube Length	385mm	385mm	405mm	425mm	445mm	465mm
Seat Tube Angle (Low BB)	77.7°	77.7°	77.5°	77.2°	77°	76.9°
Seat Tube Angle (High BB)	78.2°	78.2°	77.9°	77.7°	77.5°	77.3°
Max Seatpost Insertion	190mm	190mm	210mm	230mm	250mm	270mm
Min Seatpost Insertion	100mm	100mm	100mm	100mm	100mm	100mm
